| SR9830 Three Channels Digital Electrocardiograph |
| Code |
Product Name |
Remark |
| SR9830 |
Three Channels Digital Electrocardiograph |
Input Circuit: Isolated |
| Safety Level: IEC Class 1 Type CF |
| Input Impedance: ≥50MΩ |
| Imput Circuit Current: ≤0.1μA |
| Noise Level: ≤15μVp-p |
| Patient urrent Leakage: <10μA |
| CMRR: >100dB |
| Frequency Response: 0.05 - 150Hz |
| Time Constant: ≥3.2 Second |
| Polarizing Voltage: ±500mV |
| Sensitivity: 2.5, 5, 10, 20mm / mV ±3% |
| Paper Speed: 25mm/s, 50mm/s |
Power Requirements:
AC:100-240V, 50-60Hz
DC: Built in Charge & Li-ion Battery Supports ontinuous Operation For More than One Hour After Completerly charged |
| N.W. (kg): 2 |
| Dimension(LxWxH): 280x216x66mm | |
|
