| SR-A1200 Twelve Channels Digital Electrocardiog^ |
| Code |
Product Name |
Remark |
| SR-A1200 |
Twelve Channels Digital Electrocardiograph |
Input Circuit: Floating |
| Safety Level: IEC Class 1 Type CF |
| Input Impedance: ≥50MΩ |
| Imput Circuit Current: ≤0.1μA |
| Noise Level: ≤15μVp-p |
| Patient urrent Leakage: <10μA |
| CMRR: >100dB |
| Frequency Response: 0.05 - 150Hz |
| Time Constant: ≥3.2 Second |
| Polarizing Voltage: ±500mV |
| Sensitivity: 2.5, 5, 10, 20mm / mV ±3% |
| Paper Speed: 5(6.25), 10(12.5), 25, 50mm/s |
Power Requirements:
AC:100-240V, 50-60Hz 60V
ADC:14.4V Rechargeable Li-ion Battery |
| N.W. (kg): 5.3 |
| Dimension(LxWxH): 400x320x80mm | |
|
